3QL Ridging Plough

1. It's mainly used for ridging in the field with potato, beans, vegetables after tillage;
2. It's convenient to adjust the ridging spacing, ridging height, ridging rows.

  • 3QL
  • FOTMA

3QL series of ridging plough is mainly used for ridging in the field with potato,beans,vegetables after tillage.It has the advantages of convient adjustment in ridging spacing,ridging height,ridging rows and angle,wide range of matched tractors,good ability of adaption and so on.

Features:
1. The depth & size is adjustable;
2. With two tyres, convenience for transport;
3. The tyne can be increased & decreased as per requirement.

Model  3QL-3 3QL-4 3QL-5
Working width(mm) 2500 3200 3900
Ridging space(mm) 700~900 700~900 700~900
Ridging height(mm) 200~250 200~250 200~250
matched power(hp) 40 60 80
