| MAIN SPECIFICATIONS |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Tractor Parameters | Model | DF200 | DF204 | DF250 | DF254 |
| Drive Type | 2WD | 4WD | 2WD | 4WD |
| Overall Dimensions L×W×H（mm）: | 3220×1360×1460
(Height to steering wheel) |
| Wheel Track（mm） | Front | 975 | 984 | 975 | 984 |
| Rear | 1,020,112,012,201,320 |
| Wheel Base（mm） | 1619 | 1638 | 1619 | 1638 |
| Ground Clearance（mm） | 400 | 292 | 400 | 292 |
| Construction Mass（kg） | 1040 | 1190 | 1040 | 1190 |
| Theoretical(km/h) | Forward | 1.11,1.29,2.90,5.06,5.75,9.26,15.02,26.02 |
| Reverse | 1.44,7.45 |
| Engine Specifications | Model | 380T | ZN390T |
| Type | 3-cylinder,Upright inline cylinder, radiator cooling, 4-storke cycle, swirl chamber |
| 12-hour Rated Power(kW/hp) | 14.7/20.0 | 18.4/25.0 |
| Rated Speed（rpm） | 2400 | 2350 |
| Bore ×Stroke（mm） | 80×90 | 85×90 |
| Total Displacement（L） | 1.375 | 1.532 |
| Drive System | Clutch | dual-stage |
| Gear Box | (4+1)×2 |
| Main Drive | one pair of spiral bevel gears |
| Differential | bevel gear |
| Differential Lock | jaw lock |
| Final Transmissions | spur gear,external gearing |
| Traveling Mechanism | Tire | Front | 4.00-16 | 6.00-12 | 4.00-16 | 6.00-12 |
| Rear | 8.3-24 | 83.-24 | 9.5-24 | 9.5-24 |
| Steering Gear | full hydraulic steering |
| Brake | disc typre |
| Working Device | Hydraulic System | Lifting Capacity at 610 mm Behind Lift Point（kg） | 432kg |
| 3-Point Suspension | category: Ⅰ |
| P.T.O. Shaft | Rotating Speed（rpm） | 540/1000 |
| Spline Size | 6-ф35 Rectangular Spline |
