DF404AU Tractor

40HP, 4WD

  • Dongfeng, DF
Model DF-404B (40HP, 4WD)
Dispositions:
(1)Dual-function clutch
(2)Twin turning speeds of P.T.O. (540/1000 rpm)
(3)Power steering
(4)Metal sheet hood & fenders
(5)Combination meters
(6)Front balance
(7)High Quality seat with safety belt
(8)Disc brake
(9)Swing drawbar
(10)Folding ROPS + Sunshade

Option:
Specification
(1) Rear Wheel Ballast
(2) Hydraulic output



Tractor
Parameters
Model DF-404B
Drive Type 4×4 4WD
Overall Dimensions L×W×H(mm): 3460×1500×1620
(Height to steering wheel)
Wheel Track(mm) Front 1200
Rear 1100, 1200, 1300, 1400
Wheel Base(mm) 1818
Ground Clearance(mm) 358
Rated Traction Force(N) In Paddy Fields 5760
In Dry Fields 7860
Construction Mass(kg) 1485
Min. Turning Radius(m) 3.20
Theoretical(km/h) Forward 1.75, 2.88, 4.63, 6.21
9.05, 14.90, 23.98, 32.20
Reverse 2.37, 12.28
Engine
Specifications
Model ZN490BT
Type 4-cylinder, Vertical, in-line cylinder arrangement, radiator cooling, 4-stroke cycle
Rated Power(kW/hp) 29.4/40
Rated Fuel Consumption (g/kW/h) ≤275
Rated Speed(rpm) 2400
Bore ×Stroke(mm) 90×100
Total Displacement(L) 2.543
Drive
System
Clutch Linkage Type Dual-function Clutch
Gear Box (4+1)×2
Main Drive One Pair of Spiral Bevel Gears
Differential Bevel Gear
Differential Lock Jaw Lock
Final Transmissions Spur Gear, External Gearing
Traveling
Mechanism
Tire  Front 7.50-16
Rear 12.4-24
Steering Gear Full Hydraulic Steering
Brake Disc type
Working
Device
Hydraulic System Lifting Capacity at 610 mm Behind Lift Point(kg) 665
3-Point Suspension Category: Ⅰ
P.T.O. Shaft Rotating Speed(rpm) 540/1000
Spline Size 6-ф35 Rectangular Spline
