Model | DF600 | DF604 | DF650 | DF654 |
ENGINE |
Type | 4 Cyl., direct-injection, water-cooled 4-cycle diesel engine |
Engine Gross, HP(kW) | 60(44.1) | 65(48.0) |
PTO, HP(kW) | 51.6(37.9) | 55.9(41.3) |
Rated Speed, rpm | 2300 | 2300 |
Displacement, L | 4.33 | 4.33 |
Fuel Tank Capacity, L | 95 | 95 |
Drive Train | |
Transmission | Collar shift 12F/4R |
Constant mesh |
Synchro Shuttle (Option) | Collar shift 12F/12R |
Min/Max forward speed, km/h | 1.5-34.7 | 1.5-33.7 |
Steering | Power |
Clutch | Dry, dual-stage |
Brake | Wet, multi-disk |
Differential Lock | Mechanical |
Drive Type | 2WD | 4WD | 2WD | 4WD |
PTO |
Rear PTO, rpm | Live 540/1,000 |
Spline Size | 6-035 Rectangular spline |
Hydraulics | |
Pump Type | Gear(tandem) |
Implement Pump, L/min | 36.8 | 36.8 |
Remote Valves (Option) | 2 |
3-Point Hitch | CAT.2 |
Control Type | Position, Draft, Mixed control |
Lift Capacity 610mm behind @ lift balls, kg | 1200 |
Dimensions |
Overall Length, mm | 4,040 | 4,040 |
Overall Width, mm | 1,845 | 1,845 |
Overall Height(Top of Cab), mm | 2,400 | 2,400 |
Wheelbase, mm | 2,060 | 2,080 | 2,060 | 2,080 |
Min. Ground Clearance, mm | 450 | 310 | 450 | 310 |
Min.Turning Radius, m | 3.8 | 4.2 | 3.8 | 4.2 |
Weight, kg | 2,150 | 2,305 | 2,180 | 2,400 |
Tires |
AG, Front /Rear | 6.5-16/14.9-28 | 8.3-24/14.9-28 | 6.5-20/14.9-30 | 8.3-24/14.9-30 |
