Model | DF800 | DF804 | DF850 | DF854 |
ENGINE |
Type | 4 Cyl., direct-injection, water-cooled 4-cycle diesel engine |
Engine Gross, HP(kW) | 80(59.0) | 85(62.5) |
PTO, HP(kW) | 68.8(50.7) | 73.1(53.8) |
Rated Speed, rpm | 2300 | 2300 |
Displacement, L | 4.94 | 4.94 |
Fuel Tank Capacity, L | 95 | 95 |
Drive Train | |
Transmission | Collar shift 12F/4R |
Constant mesh |
Synchro Shuttle(Option) | Collar shift 12F/12R |
Min/Max forward speed, km/h | 1.5-35.3 | 1.5-35.3 |
Steering | Power |
Clutch | Dry, dual-stage |
Brake | Wet, multi-disk |
Differential Lock | Mechanical |
Drive Type | 2WD | 4WD | 2WD | 4WD |
PTO |
Rear PTO, rpm | Live 540/1,000 |
Spline Size | 6-035 Rectangular spline |
Hydraulics | |
Pump Type | Gear(tandem) |
Implement Pump, L/min | 36.8 | 36.8 |
Remote Valves (Option) | 2 |
3-Point Hitch | CAT. 2 |
Control Type | Position, Draft, Mixed control |
Lift Capacity 610mm behind@ lift balls, kg | 1500 |
Dimensions |
Overall Length, mm | 4,120 | 4,120 |
Overall Width, mm | 1,980 | 1,980 |
Overall Height(Top of Cab), mm | 2,630 | 2,630 |
Wheelbase, mm | 2,060 | 2,080 | 2,060 | 2,080 |
Min. Ground Clearance, mm | 530 | 380 | 530 | 380 |
Min.Turning Radius, m | 3.8 | 4.2 | 3.8 | 4.2 |
Weight, kg | 2,440 | 2,670 | 2,440 | 2,670 |
Tires |
AG, Front /Rear | 7.5-16/14.9-30 | 8.3-24/14.9-30 | 7.5-16/14.9-30 | 8.3-24/14.9-30 |
