| Technical parameters |
|
| Drive type | 4*2 |
| Overall dimension(L * W * H) | 4030*1650*(2150/2520) |
| Wheelbase (mm) | 2016 |
| Track(front/rear) | 1150-1450/1200-1500 |
| Track(front/rear) regulating method | Step/stepless |
| Min.Ground clearance(mm) | 400 |
| Min.operating weight (with cab)(kg) | 2300 |
| Min.operating weight (without cab)(kg) | 2120 |
| Counterweight (max)(front/rear) | 108.144/300.360 |
| Gears(forward/reverse/creeper) | 8+4/8+8/12+12/16+8 |
| Theoretical speed of each gear(forward/reverse) | 2.65-34.87/3.94-12.1;2.65-34.87/2.33-30.49;0.37-29.91/0.55-10.25;2.24-29.91/1.97-26.22 |
| Engine |
|
| Brand | Quanchai |
| Engine type | 4-cylinder |
| Intake mode | Natural intake |
| Number of cylinders | 4 |
| Bore | 105 |
| Stroke | 118 |
| Displacement(L) | 4.087（QC4105） |
| Engine rated power kW@rpm | 44 |
| Rated speed | 2400 |
| Type of air cleaner | Dry or wet type |
| Type of cooling system | Forced water-cooled |
| Max. Torque@ revolving speed (rpm) | 235@1600~1800 |
| Specific fuel consumption rate at rated conditions (g/kW.h) | ≤248 |
| Fuel tank capacity (L) | 23/45 |
| Steering brake system |
|
| Type of steering system | Hydraulic/mechanical |
| Type of steering gear | Cycloid orbitrol steering gear |
| Type of braking system | Disc type |
| Transmission system |
|
| Clutch type | Single-action/double action |
| Gearbox type | Two-axis mechanical gearbox |
| Gearbox shift mode | Shift sleeve |
| Type of central transmission | Spiral bevel gear type |
| Final transmission mode (front/rear) | Planetary gear type |
| Walking system |
|
| Frame type | Frameless |
| Tire Model (front/rear) | 6.0-16/12.4-28 |
| Working device |
|
| Type of hydraulic suspension system | Open-center, semi-separated type |
| Type of linkage | Three point rear linkage |
| Linkage classes | Class II |
| Lift capacity(610mm point))kN | 11.5 |
| Regulating mode | Force or position independent control |
| Type of PTO shaft | Rear semi-detached type |
| The number of PTO shaft splines | 6 splines/8splines |
| Outer diameter of PTO shaft spline | φ35/φ38 |
| PTO shaft speed | 540/760 or 540/1000 or 760/1000 |
| Hydraulic system |
|
| Hydraulic output flow (L/min) | 23 |
