| Technical parameters |
|
| Drive type | 4*4 |
| Overall dimension(L * W * H) | 3312*1524*2255 |
| Wheelbase (mm) | 1775 |
| Track(front/rear) | 1243/960～1460 |
| Track(front/rear) regulating method | Fixed/stepless |
| Min.Ground clearance(mm) | 290 |
| Min.operating weight (kg) | 1600 |
| Counterweight (max)(front/rear) | 54/180 |
| Gears(forward/reverse/creeper) | 8+2/8+8 |
| Theoretical speed of each gear(forward/reverse) | 1.72-26.02/2.25-10.39；1.72-26.02/1.61-24.24； |
| Engine |
|
| Brand | Laidong, Jiangdong, lijia |
| Engine type | In-line, four-stroke |
| Intake mode | Natural intake |
| Number of cylinders | 3 |
| Bore | 75 |
| Stroke | 105 |
| Displacement(L) | 2 |
| Engine rated power kW@rpm | 22.1 |
| Rated speed | 2350 |
| Air cleaner type | Dry or wet type |
| Type of cooling system | Water-cooled |
| Max. Torque@ revolving speed (rpm) | ≥96/1650 |
| Specific fuel consumption at rated conditions (g/kW.h) | ≤244 |
| Fuel tank capacity (L) | 29 |
| Steering brake system |
|
| Type of steering system | Hydraulic/mechanical |
| Type of steering gear | Cam and roller steering gear/cycloid orbitrol steering gear |
| Type of braking system | Shoe type |
| Transmission system |
|
| Clutch type | Single-action/double action |
| Gearbox type | Two-axis mechanical gearbox |
| Gearbox shift mode | Shift sleeve +sliding gear |
| Type of central transmission | Spiral bevel gear type |
| Final transmission mode (front/rear) | Built-in type, single-stage spur gear |
| Walking system |
|
| Frame type | Frameless |
| Working device |
|
| Type of hydraulic suspension system | Open-center, separated type |
| Type of linkage | Three point rear linkage |
| Linkage classes | Class 0 or class I |
| Lift capacity(610mm point))(kN) | 6.2 |
| Regulating mode | Positioning control and floating control |
| Type of PTO shaft | Non-independent type |
| The number of PTO shaft splines | 6 splines/8splines |
| Outer diameter of PTO shaft spline | φ35/φ38 |
| PTO shaft speed | 540/760 or 540/1000 |
| Hydraulic system |
|
| Hydraulic output flow (L/min) | 26 |
