Jinma 504 Tractor

  • Jinma, JM

Tracor
Parameters

Model

JM-504

Drive Type

4WD

Overall Dimensions  L*W*H(mm):

3946*1625*2220

Wheel Track  (mm)

Front

1300

Rear

1300-1600

Wheel Base(mm)

2073

Ground Clearance (mm)

Under Front Axle

325

Under Rear Axle

370

Rated Traction Force(N)







13000

Construction Mass(kg)

2148

Min.Turning Radius(m)

3.42

Theoretical Speed (With out creeper gear(km/h)

Forward

2.243,3.293,5.355,7.031,10.070,14.793,24.049,31.579

Reverse

3.327,4.888,7.945,10.433

Theoretical Speed (With creeper gear(km/h)

Forward

0.336,0.493,0.802,1.053,1.508,2.214,3.600,4.725

Reverse

0.500,0.732,1.190,1.562

Engine
Specifications

Model

SL4100BT

Type

4-Cylinder 4-stroke cycle water cooled

Rated Power(kw/hp)

36.8/50

Rated Speed (rpm)

2300

Bore*Stroke(mm)

100*110

Total Displacement(L)

3.456

Drive
System

Clutch

Single-function dry constant meshing

Gear Box

4*(2+1)Sleeve gear

Main Drive

One Pair of Spiral Bevel Gearing

Differential

Bevel gear

Differential Lock

Sliding pin,foot operated

Final Displacement(L)

Planeatry reduction gear

Travelling
Mechanism

Tyre

Front

8.3-20

Rear

12.4-28

Steering Gear

Hydraulic steering

Brake

Oil immerszd multiplate disc

Working
Device

Hydraulic System

Lifting Capacity at 610mm Behind Lift Pioint (N)

8300

3-Point Suspension

Category:I

P.T.O
Shaft

Rotating
Speed (rpm)

540/1000
Or 540/1000

Spline Size

6-Φ35Rectangular Spline

OPTIONS SAFETY FRAME,CANOPY,CREEPER,SHUTTLE,SYNCHRONISED GEAR,CAB
