FOTMA
| Without cab & canopy | |||
| Item | FM300 | FM304 | |
| Complete Parameter | |||
| Drive Form | 4*2 | 4*4 | |
| Rated traction force (KN) | 6.37 | 7.84 | |
| Main output power of P.T.O. (KW) | ≥19.89 / ≥19.80 | ||
| Constructional weight (Kg) | 1365 / 1240 | 1525 / 1450 | |
| Wheel base (mm) | 1890 / 1705 | 1875 / 1755 | |
| Front wheel tread (mm) | 1125(adjustable) | 1175 | |
| Rear wheel tread (mm) | 1170(adjustable) | 1170(adjustable) | |
| Turning radius (m) | With one-side braking | 3.2 / 2.9±0.2 | 3.0±0.2 |
| Without one-side braking | 3.5 / 3.2±0.2 | 3.8±0.2 | |
| Figure size L*W*H (mm) | 3200*1510*2020 / 3105*1510*2105 | 3280*1455*2025 / 3125*1455*2115 | |
| Minimum land clearance (mm) | 440 | 335 | |
| Front tyre | 5.0-15 | 6.5-16 | |
| Rear tyre | 11.2-24 | ||
| Fuel tank capacity (L) | 50 | ||
| Engine | |||
| Model | ZN390T / SD2100TA | ||
| Bore × Stroke (mm) | φ90×95 / φ100×115 | ||
| Rated revolution (r/min) | 2350 / 2200 | ||
| Rated power (KW) | 22.10 / 22.00 | ||
| Max. torque (N.m) | ≥105.00 / ≥109.80 | ||
| Revolution when it is max. torque (r/min) | ≤1760 / ≤1650 | ||
| Fuel consumption (g/Kw.h) | ≤255 / ≤250 | ||
| Oil consumption (g/Kw.h) | ≤2.27 / ≤1.84 | ||
| Transmission | |||
| Clutch | Single stage, dry type | ||
| Gear box | Straight teeth (4+1)*2 plane combined | ||
| Hydraulic pressure raiser and suspension | |||
| P.T.O type | Postposition, not independent. | ||
| Speed of P.T.O (r/min) | 540/1000 or 750/1000 or 540/750 | ||
| Lifter tilling depth control | positional adjustable | ||
max lifts capacity at the point of 610mm from suspending shaft backward (KN) | ≥4.97 / ≥4.95 | ||
| Suspension type | Postposition, Three-point, I category. | ||
| Note: The whole size and weight will be different slightly because of the devices vary. | |||
