FOTMA
Model | Tractor Front Mounted | CX130 | CX160 | CX180 | CX210 |
Rear 3-point Hitched | CX130-R | CX160-R | CX180-R | CX210-R | |
For Front 3-point Linkage | CX130-XG | CX160-XG | CX180-XG | CX210-XG | |
For Front End Loader | CX130-TZ | CX160-TZ | CX180-TZ | CX210-TZ | |
Matching Tractor (hp) | 20 〜40 | 40 〜60 | 60 〜90 | 80 〜120 | |
Blowing Width (mm) | 1300 | 1600 | 1800 | 2100 | |
Blowing Height (mm) | 600 | 600 | 600 | 600 | |
Number of Blades | 4 | 4 | 4 | 4 | |
Di a. of Fan (mm) | 500 | 500 | 500 | 500 | |
Dia. of Feeding Spiral (mm) | 360 | 360 | 360 | 360 | |
Power of Driven Motor (hp) | 15 | 20 | |||
Adjustable Angle of Snow Outlet | 360 ° | ||||
Adjustable Type of Outlet Direction | Manual Adjustment (standard) Electric Adjustment (option) | ||||
Weight (kg) | 200-300 | 220-330 | 240-370 | 260-420 |
