YTO-C1402 Crawler Tractor

Quantity:
  • YTO

140HP Crawler Tractor

Featrures
1. Our 140HP crawler tractor is produced with diesel engine. The British technology provides large torque and powerful loading capacity. Consuming less fuel, this range of product is environment friendly.

2. The (2+1)×4 gearbox with goggle sleeve shift is adopted to increase the gear centre distance and improve the gear strength. Moreover, the big gearbox housing effectively increases the volume for lubricating liquid.

3. This agricultural vehicle has wide range of operating speed, which can fully meet the requirement for different applications.
4. The 14 double disc dry type main clutch with compression spring, as well as the friction plate with damping spring, contributes to the reliable torque transmission and long service life.

5. Manufactured with mature technology, the wet steering clutch for 140HP crawler tractor requires no adjustment during operation.

6. The self-lubricating bearing specially offered for the operating mechanism can effectively reduce the operating force. More importantly, less maintenance is required for normal operation.

7. According to the characteristic of the farm work and bulldozing, the crawler tractor with cab is specially optimized through the adjustment on the gravity center to improve the lifting force.

8. Rubber track is optional for high trafficability and steering performance of the eco-friendly crawler tractor.

9. Featuring nice appearance and broad vision, the cab can be equipped with heating system, air condition, and audio system for comfortable operation.

Model C1402
140HP crawler tractor
Overall dimension (L×W×H) (mm)(without dozer blade) 5344×1835×2910
Min. operating mass (kg)(without dozer blade) 7400
Track gauge (mm) 1435
Wheelbase (mm) 1792
Track shoe width (mm) 390
Ground pressure (kPa) 47.7
Diesel engine
Model LR6M3Z-23
Type In-line, water cooled, four stroke, supercharged
Rated power and rotating speed (kW/rpm) 103/2200
Gearbox
Gear shift (F/R) 8/4
Speed range (km/h) (F/R) 3.9-13.6/4.44-7.74
Power of PTO shaft (kW) 87
PTO rotating speed (rpm) 720/540 (optional)
Clutch Double disc, single acting
Working device
Suspension type Rear-mounted two-point or three-point suspension (type II)
Plowing depth control method Height adjustable
Lifting force (KN) 14.6
Size of dozer blade (W×H)(mm) 2462×850
Embedded depth of dozer blade (mm) 330
