4. This agricultural half-track tractor can be installed with oil separator for powerful lifting force. Moreover, the forced soil penetrating device is optional, as well.
5. The pneumatic brake system and the 1/2/3 groups hydraulic output multiway valve are available according to the actual demand of the customer.
6. The heating system, air condition, and the audio system are selectable for cab of the agricultural vehicle. The comfortable driving will bring you high working efficiency.
7. The transfer box and rear track of the eco-friendly half track tractor is interchangeable with that of YTO-X904 series. So it can be used as a wheeled tractor.
4. This agricultural half-track tractor can be installed with oil separator for powerful lifting force. Moreover, the forced soil penetrating device is optional, as well.
5. The pneumatic brake system and the 1/2/3 groups hydraulic output multiway valve are available according to the actual demand of the customer.
6. The heating system, air condition, and the audio system are selectable for cab of the agricultural vehicle. The comfortable driving will bring you high working efficiency.
7. The transfer box and rear track of the eco-friendly half track tractor is interchangeable with that of YTO-X904 series. So it can be used as a wheeled tractor.
Model | LX904CS |
YTO-LX904CS half-track tractor | |
Overall dimension (L×W×H) (mm) (without dozer blade) | 4350×2400×2765 |
Min. operating mass (kg) | 4450 |
Front wheel tread (mm) | 1562-2000 |
Rear track gauge (mm) | 1720 |
Wheelbase (mm) | 2314 |
Track shoe width (mm) | 550 |
Ground pressure (kPa) | 30 |
Ground contact length (mm) | 1020 |
Diesel engine | |
Model | LR4M5-23 |
Type | In-line, water cooled, four stroke |
Rated power and rotating speed (kW/rpm) | 66.5/2300 |
Gearbox | |
Gear shift (F/R) | 12/4 |
Speed range (km/h) (F/R) | 0.74-12.09/1.92-5.72 |
Power of PTO shaft (kW) | 55 |
PTO rotating speed (r/min) | 720 (optional), 540, 800, 1000, 540/1000, 540/720, 720/800 |
Clutch | Single disc, double acting |
Working device | |
Suspension type | Rear-mounted three-point suspension (type II) |
Plowing depth control method | Force control, position control, integrated force and position control, floating control |
Lifting force (KN) | 17 |
Rated traction (KN) | 19.8 |
