Zoomlion RF254 Tractor

Quantity:
  • Zoomlion
1.Direct injection engine, energy-saving, environmental protection, powerful, large torque reservation, good stability and more technologically-advanced.
2.Enhanced chassis, large tractive force, dual power output, powerful and high efficiency.
3.Applies 8F+2R gear, optional 8F+8R sleeve shuttle shift, more suitable for variety of fields operation and transportation; low fuel consumption, better performance.
4.Lighter weight, with good sealing, more suitable for paddy field operation.
5.Enclosed brakemaking stable and reliable braking.
6.Double-action clutch,easy operation and reliable.
7.A wide range of agricultural implements. Planetary gear reducer applies higher reduction ratio, high driving strength.
8.Ergonomic design and comfortable riding.
Model RF254
Drive Type 4×4
Overall Demension(L×W×H) (mm)
3312*1610*2300
Rated Power (kw) 18.4
Engine Cylinder 3
Rated Traction (kN) 5.7
PTO r/min 540/1000
Front Wheel Tread (mm) 1200
Rear Wheel Tread (mm) 1100/1200/1300(1200/1300)
Wheelbase (mm) 1739(1847)
Min.Ground Clearance 358(395)
Max.Lifting Force (kN) ≥4.2
Gearbox 8F+2R(8F+8R)
Tire 6.0-16/12.4-24(6.5-16/11.2-24)
●Standard Configuration
CHANGCHAI Engine/Dual Action Clutch/Simple Hydraulic Output / Fixed Drawbar / Outer Air Filters
●Optional Configurations
Dual Action Clutch / PTO:540/730 / 2 Pairs of Hydraulic output / Air Brake / Swing Drawbar / ROPS / Fixed Cabin(Fan or Heater)/Foldable Cabin(Fan or Heater)/Counterweight (Front and Rear)/4×2
