Cummins
GENSET MODEL | UNIT | GB20SC | GB24SC | GB30SC | GB40SC | |
DIESEL ENGINE | TYPE | | In-line,4Cylinder,4 Cycle,Natural Engine | In-line,4 Cylinder,4 Cycle,Tubocharged Engine | In-line,4 Cylinder,4 Cycle,Watercooled Turbocharged Engine | |
COMPRESSION RATION | | 16.5:1 | ||||
DISPLACEMENT | L | 3.9 | ||||
RATED SPEED | R/MIN | 1500/1800 | ||||
RATED OUTPUT | (KW) | 24(27) | 36(40) | 50(60) | ||
STANDBY POWER | KW | 27 | 40 | 55 | ||
GENSET MATCHING POWER | KW | 20 | 30 | 40 | ||
FUEL INJECTION PUMP | | A Injection Pump | ||||
STEADY SPEED DROOP | | ≤1%(Electrical Governor) | ≤1% | |||
| | ≤6%(Mechanical Governor) | | |||
ENGINE MODEL | | 4B3.9-G | 4BT3.9-G | 4BTA3.9-G | ||
COOLING WAY | | Positive Water Cooling Cycle | ||||
ALTERNATOR | MODEL(Stamford) | | BCI184F | BCI184G | BCI184H | UCI224D |
RATED POWER | KW | 18/20 | 24 | 30 | 40 | |
RATED VOLTAGE | (V) | 400/230; 380/220; etc | ||||
RATED FREQUENCY | | 50HZ/60HZ | ||||
VOLTAGE REGULATION | | AVR | ||||
EXCITATION METHOD | | BRUSHLESS | ||||
| CONTROL PANEL(standard) | | V-meter,A-meter,Frequency meter , circuit breaker,transfer switch,AVR, temp. and pressure gauges, lighter,hour meter, key starter, etc. | |||
OVERALL DIMENSIONS | L*W*H(mm) | 2300*1100*1300 | ||||
NET WEIGHT | (kg) | 800 | 840 | 1000 | 1200 |
