DF200 tractor

20HP, 2WD
Quantity:
  • Dongfeng, DF

  • 属性值

The DONGFENG Brand wheeled tractor of Model DF-200/204 is a newly developed product series. It is powered with the three-cylinder diesel engines that have the features of ample output,less vibration and low noise as well.

Model DF-200/204 tractors are of dual-function type for using in both paddy and dry fields. The designers have cogitated on some components, which can be selected for assembling in order to meet users’ various needs.

In order to fit in with the international market, some components for perfecting the tractor have been designed and developed, such as the hydraulic power steering, two-speed PTO and so on. All of these have improved the performance of the tractor greatly.

This tractor series has the advantages of economic fuel consumption, easy operation, harmonious appearance, compact construction and simple maintenance. It has eight forward gears and two reverse gears, the speeds range from 1.11 to 26.20 km/hr. The tractor is equipped with the linkage type double-acting clutch. It can be used for many farming jobs such as rototilling, plowing, harrowing, seeding, inter-row cultivation and harvesting if suitable farm implements are matched. Meanwhile, this tractor series may be provided with the intensified function of transporting, i.e. the air brake facilities (optional) for trailer, which can improve the safety conditions of a transporting unit (i.e. a four wheel tractor hitched with a trailer for transportation). Really, this tractor series is of an ideal type for the small or medium farms.

Main Dispositions:

 Dual-function clutch
 Twin turning speeds of P.T.O.
 Power steering
 Safe start switch
 Fiberglass hood
 Combination meters
 Quality seat system
 Seat belt

Options:

 Folding ROPS
 Sun shade
 Spring seat system
 Turf tyre
 Industrial tyre
 EPA Engine
 Hydraulic outlet

Tractor
Parameters

Model

DF-200

Drive Type

2WD

Overall Dimensions
L×W×H(mm)

2800×1350×1460
Height steering wheel

Wheel Track(mm)

Front

975(Usually use)
1175,1275,1375

Rear

1020,1120,1220,1320

Wheel Base(mm)

1619

Ground
Clearancre(mm)

Under Front Axle

400

Under Rear Axle

290

Rated Traction

Force(N)

In Paddy Fields

3600

In Dry Fields

5250

Construction Mass(Kg)

1040

Min. Turning Radius(m)

2.40

Theoretical
Speed(Km/h)

Forward

1.11,1.29,2.90,5.06,5.75,9.26,15.02,26.20

Reverse

1.44,7.45
Engine
Specifications

Model

Y380T

Type

3-cylinder,Upright inline cylinder,
radiator cooling,4-storke cycle

12-hour Rated Power(Kw/hp)

14.7/20.0

Rated Speed(rpm)

2400

Bore×Stroke(mm)

80×90

Total Displacement(L)

1.375
Drive
System

Clutch

Dual-stage

Gear Box

(4+1)×2

Main Drive

One Pair of Spiral Bevel gears

Differential

Bevel Gear

Differential Lock

Jaw Lock

Final Transmissions

Spur Gear,External Gearing
Travelling
Mechanism

Tyre

front

4.00-16(stripe pattern)

rear

8.3-24(herringbone pattern)

Steering Gear

Full Hydraulic steering

Brake

Disk type
Working
Device

Hydraulic
System

Lifting Capacity at
610 mm Behind Lift
Point(Kg)

432kg

3-point Suspension

Category:I

P.T.O.Shaft

Rotating
Speed(rpm)

540/1000

Spline size

6-φ35 Rectangular spline
