DF350 Tractor

35HP, 2WD
Quantity:
  • Dongfeng, DF

The DONGFENG Brand wheeled tractor of Model DF-350/354 is a newly developed product series. (Changzhou Tractor Plant). It is powered with the three-cylinder diesel engines that have the features of ample output,less vibration and low noise as well.

Model DF-350/354 tractors are of dual-function type for using in both paddy and dry fields. The designers have cogitated on some components, which can be selected for assembling in order to meet users’ various needs.

In order to fit in with the international market, some components for perfecting the tractor have been designed and developed, such as the hydraulic power steering, two-speed PTO and so on. All of these have improved the performance of the tractor greatly.

This tractor series has the advantages of economic fuel consumption, easy operation, harmonious appearance, compact construction and simple maintenance. It has eight forward gears and two reverse gears, the speeds range from 1.37 to 30.05km/hr. The tractor is also equipped with the linkage type double-acting clutch. It can be used for many farming jobs such as rototilling, plowing, harrowing, seeding, inter-row cultivation and harvesting if suitable farm implements are matched. Meanwhile, this tractor series may be provided with the intensified function of transporting, i.e. the air brake facilities (optional) for trailer, which can improve the safety conditions of a transporting unit (i.e. a four wheel tractor hitched with a trailer for transportation). Really, this tractor series is of an ideal type for the small or medium farms.

Main Dispositions:
 Dual-function clutch
 Twin turning speeds of P.T.O.
 Power steering
 Saft start switch
 Fiberglass hood
 Combination meters
 Quality seat system
 Seat belt

Options:
 Folding ROPS
 Sun shade
 Spring seat system
 Turf tyre
 Industrial tyre
 EPA Engine
 Hydraulic outlet

Tractor
Parameters

Model

DF-350

Drive Type

2WD

Overall Dimensions
L×W×H(mm)

3370×1500×1620(Height to steering wheel)

Wheel Track(mm)

Front

1100,1200,1300,1400

Rear

1100(Usually use),1200,1300,1400

Wheel Base(mm)

1735

Ground
Clearancre(mm)

Under Front Axle

420

Under Rear Axle

378

Rated Traction

Force(N)

In Paddy Fields

4270

In Dry Fields

6560

Construction Mass(Kg)

1290

Min. Turning Radius(m)

2.80

Theoretical
Speed(Km/h)

Forward

1.66,2.74,4.41,5.92,8.62,14.20,22.85,30.68

Reverse

2.19,11.36
Engine
Specifications

Model

TY395

Type

3-cylinder,Upright inline cylinder
radiator cooling,4-storke cycle,direct-injetion

Rated Power(Kw/hp)

25.80/35.0

Rated Fuel Consumption(g/kw/h)

≤251.6

Rated Speed(rpm)

2400

Bore×Stroke(mm)

95×105

Total Displacement(L)

2.23
Drive
System

Clutch

Linkage type dual-function clutch

Gear Box

(4+1)×2,plannar 3-shaft for main transmission
epicyclic gearing for auxiliary transmission

Main Drive

One Pair of Spiral Bevel gears

Differential

Bevel Gear

Differential Lock

Jaw Lock

Final Transmissions

Spur Gear,External Gearing
Travelling
Mechanism

Tyre

front

5.00-15

rear

12.4-24

Steering Gear

Hydraulic streering

Brake

Disk type
Working
Device

Hydraulic
System

Lifting Capacity at
610 mm Behind Lift
Point(Kg)

580

3-point Suspension

Category:I

P.T.O.Shaft

Rotating
Speed(rpm)

540/1000

Spline size

6-φ35 Rectangular spline
