Deutz
GENSET MODEL | UNIT | GB20SD | GB30SD | GB50SD | GB75SD | GB100SD | GB120SD | |
DIESEL ENGINE | POWER | Standby (KW) | 28 | 40 | 55 | 90 | 110 | 132 |
Rated (KW) | 25 | 36 | 50 | 80 | 100 | 120 | ||
FUEL CONSUMPTION | (g/kwh) | 239 | 228 | 221 | 227 | 216 | 216 | |
RATED SPEED | RPM | 1500 | ||||||
POWER FACTOR | | 1 FOR SINGLE PHASE; 0.8(Lag) FOR 3-PHASE | ||||||
CONNECTION TYPE | | 1-phase 3-wire; or 3-phase 4-wire | ||||||
STARTING METHOD | | ELECTRIC START WITH BATTERY | ||||||
ENGINE MODEL | | D226B-3D | TD226B-3D | TD226B-4D | TD226B-6D | TBD226B-6D | TBD226B-6D5 | |
ALTERNATOR | MODEL(STAMFORD) | | BCI184H | UCI224C | UCI224E | UCI274C | UCI274E | UCI274F |
RATED POWER | KW | 20 | 30 | 50 | 75 | 100 | 120 | |
RATED VOLTAGE | (V) | 400/230; 380/220; etc | ||||||
RATED FREQUENCY | | 50HZ | ||||||
VOLTAGE REGULATION | | AVR | ||||||
EXCITATION METHOD | | BRUSHLESS | ||||||
| CONTROL PANEL | AMF/ATS | Deep Sea 5110 digital panel, V-meter, Frequency meter , ATS,transfer switch,AVR, lighter,hour meter,engine protection device, key starter, etc. | |||||
Manual | Manual operation control system, including: V-meter,A-meter,Frequency meter , circuit breaker,transfer switch,AVR, temp. and pressure gauges, lighter,hour meter,engine protection device, key starter, etc. | |||||||
OVERALL DIMENSIONS | L*W*H(cm) | 190 * 95 * 120 | 210 * 100 * 130 | 250 * 120 * 150 | ||||
NET WEIGHT | (kg) | 850 | 980 | 1100 | 1400 | 1950 | 2200 |
GENSET MODEL | UNIT | GB20SD | GB30SD | GB50SD | GB75SD | GB100SD | GB120SD | |
DIESEL ENGINE | POWER | Standby (KW) | 28 | 40 | 55 | 90 | 110 | 132 |
Rated (KW) | 25 | 36 | 50 | 80 | 100 | 120 | ||
FUEL CONSUMPTION | (g/kwh) | 239 | 228 | 221 | 227 | 216 | 216 | |
RATED SPEED | RPM | 1500 | ||||||
POWER FACTOR | | 1 FOR SINGLE PHASE; 0.8(Lag) FOR 3-PHASE | ||||||
CONNECTION TYPE | | 1-phase 3-wire; or 3-phase 4-wire | ||||||
STARTING METHOD | | ELECTRIC START WITH BATTERY | ||||||
ENGINE MODEL | | D226B-3D | TD226B-3D | TD226B-4D | TD226B-6D | TBD226B-6D | TBD226B-6D5 | |
ALTERNATOR | MODEL(STAMFORD) | | BCI184H | UCI224C | UCI224E | UCI274C | UCI274E | UCI274F |
RATED POWER | KW | 20 | 30 | 50 | 75 | 100 | 120 | |
RATED VOLTAGE | (V) | 400/230; 380/220; etc | ||||||
RATED FREQUENCY | | 50HZ | ||||||
VOLTAGE REGULATION | | AVR | ||||||
EXCITATION METHOD | | BRUSHLESS | ||||||
| CONTROL PANEL | AMF/ATS | Deep Sea 5110 digital panel, V-meter, Frequency meter , ATS,transfer switch,AVR, lighter,hour meter,engine protection device, key starter, etc. | |||||
Manual | Manual operation control system, including: V-meter,A-meter,Frequency meter , circuit breaker,transfer switch,AVR, temp. and pressure gauges, lighter,hour meter,engine protection device, key starter, etc. | |||||||
OVERALL DIMENSIONS | L*W*H(cm) | 190 * 95 * 120 | 210 * 100 * 130 | 250 * 120 * 150 | ||||
NET WEIGHT | (kg) | 850 | 980 | 1100 | 1400 | 1950 | 2200 |
