FM100 SERIES SPECIFICATION | ||
Model | FM1000 | FM1004 |
Drive type | 4x2 | 4x4 |
Engine | ||
Engine model | YTO/YUCHAI(optional) | |
Capacity of fuel tank(L) | 150 | 150 |
Rated speed (r/min) | 2300 | |
Engine power (kw) | 73.5 | 73.5 |
Lowest fuel consumption (g/kw·h) | ≤242 | |
Transmission | ||
Clutch | Dry,Dual-stage type | |
PTO Speed(rpm) | 540/1000 or 760/1000(optional) | |
Gear shift | 8F+4R/16F+8R(optional)/8F+8R(optional) | |
Hydraulic system | ||
Hydraulic output valve | 2-Way (optional) | |
Three point linkage | ||
Category of 3-point link | Category II | |
Lifting capacity(at point of 610mm)KN | >15 | >16 |
Technical parameter | ||
Dimension LxWxH mm | 4593x2050x2810 | |
Wheel base(mm) | 2362 | 2195 |
Track base(mm) front wheel | 1485 | 1610 |
Track base(mm) rear wheel | 1620-2020 (usual 1620) | |
The smallest clearance(mm) | 476 | 379 |
Front tyre | 6.5-20 / 7.5-16(optional) | 11.2-24 |
Rear tyre | 16.9-34/18.4-30(Optional) |
