FOTMA
| FM504 and FM554 SPECIFICATION | ||||
| Model | FM504 | FM554 | ||
| Drive type | 4x4 | 4x4 | ||
| Engine | ||||
| Type of engine | Xinchai 4-cylinder(Model: A498BT) | |||
| Capacity of fuel tank(L) | 38L | |||
| Engine power at rated speed(kw) | 36.8 | 40.5 | ||
| PTO power(kw) | 33.1 | 36.5 | ||
| Rated speed (r/min) | 2400 | |||
| Transmission | ||||
| Clutch | dry,dual-stage type | |||
| PTO speed | 540/760rpm | |||
| Gear shift | 8F+4R/8F+8R(Optional) | |||
| Hydraulic system | ||||
| Hydraulic output valve | 2-Way （optional） | |||
| Three point linkage | ||||
| Category of 3-point link | rear, category I | |||
| Lifting capacity( kg) | 846 | |||
| Technical parameter | ||||
| Min.Turning radius (m) (without single side brake) | 4.1 | |||
| Overal size(LxWxH)mm | 3513x1750x2130( without cabin or ROPs) 3513x1750x2500( with cabin) | |||
| Wheel base(mm) | 2040 | |||
| The smallest clearance(mm) | 325 | 325 | ||
| Front tire | 8.3-20 | |||
| Rear tire | 12.4-28/14.9-24(optional) | |||
