Main Features: 1. Adopt Xinchai diesel engine, good reliability, large reserves of torque, low fuel consumption, high economic efficiency; 2. Double-function clutch,10 inches, high transmission capacity, reliable, comfortable manipulation; 3. Gearbox using 4 × 3(1 +1) engaging sleeve, shuttle-type gearshift, there are 12 forward gears, 12 reverse gears, reasonable match between the gears, and have high efficiency; 4. Independent power take off device, smooth transmission, large capacity, speed (540/760, 540/1000 r/min) for selection to meet the different operation requirements; 5. Full hydraulic front wheels steering, independent oil circuit for steering system, manipulating flexible, reliable, and save energy; 6. Adopt hydrostatic disc-type brakes, a large braking torque, the braking effect is good; 7. Adopt high pressure type lifting device, reliable, easy maintenance, multi-hydraulic output can be optioned; 8. Final transmission adopts planetary gear mechanism, compact structure, large reduction ratio; 9. New streamlined appearance, generous, modern, fashion; 10. Control levers can be mounted at side as optional, more convenient and comfortable.
Main Features: 1. Adopt Xinchai diesel engine, good reliability, large reserves of torque, low fuel consumption, high economic efficiency; 2. Double-function clutch,10 inches, high transmission capacity, reliable, comfortable manipulation; 3. Gearbox using 4 × 3(1 +1) engaging sleeve, shuttle-type gearshift, there are 12 forward gears, 12 reverse gears, reasonable match between the gears, and have high efficiency; 4. Independent power take off device, smooth transmission, large capacity, speed (540/760, 540/1000 r/min) for selection to meet the different operation requirements; 5. Full hydraulic front wheels steering, independent oil circuit for steering system, manipulating flexible, reliable, and save energy; 6. Adopt hydrostatic disc-type brakes, a large braking torque, the braking effect is good; 7. Adopt high pressure type lifting device, reliable, easy maintenance, multi-hydraulic output can be optioned; 8. Final transmission adopts planetary gear mechanism, compact structure, large reduction ratio; 9. New streamlined appearance, generous, modern, fashion; 10. Control levers can be mounted at side as optional, more convenient and comfortable.
Tractor Model
FM400
FM450
FM500
FM550
FM700
Drive Type
4×2
Overall Dimension L×W×H(mm)
3910×1620×2130
3860×1635×2130
33925×1728×2170
Wheel base(mm)
1940
1950
2010
Front wheel tread(mm)
1200--1500 (Common 1300)
Rear wheel tread(mm)
1200--1500(Common 1300)
Min. ground clearance(mm)
330
330
360
360
450
Min. steering radius
Unilateral brake(m)
3.3
Not unilateral brake(m)
3.7
Min. operating weight (KG)
1840
2060
2340
Gearbox gears number
12F+12R
Speed
Forward(Kw/h)
2.46-34.02
2.33-31.04
Reverse(Kw/h)
2.15-29.82
2.04-27.21
Engine
Model
C490BT-8
A495BT
A498BT-6A
A4K41T55-002
A4K43T70A
Rated power (Kw)
29.4
33.1
36.8
40.4
51.5
Rated speed (r/min)
2400
2400
2400
2400
2300
Tires spec.
Front tires
6.00-16
8.3-24
Rear tires
12.4-28
12.4-28
13.6-28
13.6-28
14.9-28
Steering Type
Full hydraulic front wheels steering
Max. lifting force( KN )
6.7
7.5
8.28
9.1
13.5
PTO
Type
Rear-mounted, Semi-independent type
Speed (r/min)
540/760 or 540/1000
Power(Kw)
≥25
≥28.1
≥31.3
≥34.3
≥43.8
Control type of ploughing depth
Height control & flotation control
Max. traction force (KN)
8.9/9.4
10
10.7
11.8
11.7
Front / rear Ballast (KG)
104/220
104/300
Notice: As our products will be improved continuously , all above parameters are subject to modification without notice.
