| Technical parameters |
| Drive type | 4*2 |
| Overall dimension(L * W * H) | 4200*1910*2745 |
| Wheelbase (mm) | 2188 |
| Track(front/rear) | 1400-1830/1430-1830 |
| Track(front/rear) regulating method | Step/Step |
| Min.Ground clearance(mm) | 395 |
| Min.operating weight (with cab)(kg) | 2775 |
| Min.operating weight (without cab)(kg) | 240/540 |
| Counterweight (max)(front/rear) | 240/540 |
| Gears(forward/reverse/creeper) | 8+2/16+4 |
Theoretical speed of each gear
(forward/reverse) | 0.67-8.44/0.376-3.34；2.95-30.37/3.34-12.04 |
| Engine |
| Brand | Lovol Power |
| Engine type | In-line, four-stroke |
| Intake mode | Natural intake |
| Cylinders Number | 4 |
| Bore | 100 |
| Stroke | 127 |
| Displacement(L) | 4 |
| Engine rated power kW@rpm | 46 |
| Rated speed | 2200 |
| Type of air cleaner | Dry or wet type |
| Type of cooling system | Forced water-cooled |
| Max. Torque@ revolving speed (rpm) | 255@1400~1600 |
Specific fuel consumption
at rated conditions (g/kW.h) | ≤248 |
| Fuel tank capacity (L) | 78 |
| Steering brake system |
| Type of steering system | Hydraulic |
| Type of steering gear | Cycloid orbitrol steering gear |
| Type of braking system | Dry type or disc type |
| Transmission system |
| Clutch type | Dry/double action |
| Gearbox type | Two-axis mechanical gearbox |
| Gearbox shift mode | Shift sleeve |
| Type of central transmission | Spiral bevel gear type |
| Final transmission mode (front/rear) | External gearing or built-in type |
| Walking system |
| Frame type | Frameless |
| Tire Model (front/rear) | 6.0-16/14.9-28 |
| Working system |
| Type of hydraulic suspension system | Open-center, semi-separated or separated type |
| Type of linkage | Three point rear linkage |
| Linkage classes | ClassⅠ/Ⅱ |
| Lift capacity(610mm point))(kN) | Ordinary Riser≥15;Forced Riser≥20 |
| Regulating mode | Semi-separated lifter: force and position combination control;
separated lifter:depth control and floating control |
| Type of PTO shaft | Rear semi-detached/rear detached type |
| The number of PTO shaft splines | 6 splines/8splines |
| Outer diameter of PTO shaft spline | φ35/φ38 |
| PTO shaft speed | 540/1000 or 540/760 |
| Hydraulic system |
| Hydraulic output flow (L/min) | 30 |
| Three Points Suspension Classes | Three Points Suspension Classes |
