Foton TB504 Tractor

Quantity:
  • FOTON

1. The fan and heater cab are optional;
2. 955mm narrow tread model can better meet the operational requirements;
3. U.S. ACTUANT combination instruments are optional;
4. The transmission with gear combinations of 8+8, 16+8, and 12+12 has a variety of gear selections, and a reasonable velocity distribution;
5. Chassis uses the four-planetary gear differential, and the power is upgraded to 60 hp;
6. EC, EPA and GOST certification models are available.
Technical parameters
Drive type
4*4
Overall dimension(L * W * H) 3980*1650*(2130/2520)
Wheelbase (mm) 1990
Track(front/rear) 1250
Track(front/rear) regulating method non-adjustable /stepless
Min.Ground clearance(mm) 310
Min.operating weight (with cab)(kg) 2335
Min.operating weight (without cab)(kg) 2135
Counterweight (max)(front/rear) 108.144/300.360
Gears(forward/reverse/creeper) 8+4/8+8/16+8/12+12
Theoretical speed of each gear(forward/reverse) 2.65-34.78/3.94-12.1;2.65-34.78/2.33-30.49;0.43-34.78/0.65-12.10;2.46-32.73/2.15-28.69
Engine
Brand Xinchai, Quanchai
Engine type 4-cylinder
Intake mode Natural intake
Number of cylinders 4
Bore 98
Stroke 105
Displacement(L) 3.168
Engine rated power kW@rpm 36.8
Rated speed 2400
Type of air cleaner Dry or wet type
Type of cooling system Forced water-cooled
Max. Torque@ revolving speed (rpm) 186@1600~1800
Specific fuel consumption rate at rated conditions (g/kW.h) ≤248
Fuel tank capacity (L) 38/52
Steering brake system
Type of steering system Hydraulic/mechanical
Type of steering gear Cycloid orbitrol steering gear
Type of braking system Disc type
Transmission system
Clutch type Single-action/double action
Gearbox type Two-axis mechanical gearbox
Gearbox shift mode Shift sleeve
Type of central transmission Spiral bevel gear type
Final transmission mode (front/rear) Planetary gear type
Walking system
Frame type Frameless
Tire Model (front/rear) 8.3-20/12.4-28
Working device
Type of hydraulic suspension system Open-center, semi-separated type
Type of linkage Three point rear linkage
Linkage classes Class II
Lift capacity(610mm point))kN 9.1
Regulating mode Force or position independent control
Type of PTO shaft Rear semi-detached type
The number of PTO shaft splines 6 splines/8splines
Outer diameter of PTO shaft spline φ35/φ38
PTO shaft speed 540/760 or 540/1000 or 760/1000
Hydraulic system
Hydraulic output flow (L/min) 23/33
