Jinma 1004B Tractor

Quantity:
  • Jinma, JM

Tractor
Parameters

Model

JM-1004B

Drive Type

4WD

Overall Dimensions   L*W*H(mm)

4800X2330X2980

Wheel Track(mm)

Front

1808-2148

Rear

1656-2156

Wheel Base(mm)

2689

Ground
Clearance(mm)

470

Rated Traction Force(N)

 24000

Construction Mass(kg)

4500

Min.Turning Radius(m)

6.8

Speed ( Withoutcreeper km/h)

Forward

2.15,3.21,3.90,6.09,4.57,6.80,8.27,12.92
9.95,14.81,18.01,28.15

Reverse

4.65,6.92,8.41,13.14

Engine
SpecificationsClutch

Model

LRC6105T79

Type

6  -cylinder 4-stroke cycle wter cooled,

Rated Power(kw/hp)

73.5/100

Rated Speed(rpm)

2400

Bore*Stroke(mm)

105*125

Total Displacement(L)

6.49

Drive
System

Clutch

 Dual Stage

Gear Box

4*(3+1)Sleeve gear shift

Main Drive

One pair of spiral bevel gear

Differential

Bevel gear

Differential Lock

Sliding pin,foot operated

Final Transmissions

Planetary reduction gear

TRavelling
Mechanism

Tyre

Front

14.9-24

Rear

16.9-38

Steering Gear

Hydraulic steering

Brake

Oil immersed multiplate disc

Working Device

Hydraulic System

Lifting Capacity at610mm Behind Lift Point(kg)

22000

3-Point Suspension

Category:Ⅱ

P.T.O.shaft

Rotating

540 OR 1000

Spkine Size

21-φ35 involute spline

OPTIONS Synchronizer gear,fans,heating,and air-conditioned cab
