Jinma, JM
Tracor | Model | JM-854 | |
Drive Type | 4WD | ||
Overall Dimensions L*W*H(mm): | 4085*1929*2568 | ||
Wheel Track (mm) | Front | 1350-1650 | |
Rear | 1370-1790 | ||
Wheel Base(mm) | 2188 | ||
Ground Clearance (mm) | 430 | ||
Rated Traction Force(N) | 18200 | ||
Construction Mass(kg) | 3245 | ||
Min.Turning Radius(m) | 4.3 | ||
Theoretical Speed (With out creeper gear(km/h) | Forward | 3.28,4.52,7.16,9.64,12.14,16.26,25.81,34.71 | |
Reverse | 3.82,13.76 | ||
Theoretical Speed (With creeper gear(km/h) | Forward | 0.76,1.02,1.62,2.18,2.74,3.67,5.86,7.84 | |
Reverse | 0.86,3.11 | ||
Engine | Model | LRC4108T79X | |
Type | 4-cylinder 4-stroke cycle water cooled | ||
Rated Power(kw/hp) | 62.5(82) | ||
Rated Speed (rpm) | 2300 | ||
Bore*Stroke(mm) | 108*135 | ||
Total Displacement(L) | 4.95 | ||
Drive | Clutch | Dual stage | |
Gear Box | (4+1)*2*2 Sleeve gear shift | ||
Main Drive | Onepair of spiral bevel gearing | ||
Differential | Bevel gear | ||
Differential Lock | Sliding pin,foot operated | ||
Final Transmission | Planeatry reduction gear | ||
Traveling | Tyre | Front | 8.3-24 |
Rear | 14.9-30/16.9-30 | ||
Steering Gear | Hydraulic steering | ||
Brake | Disc type | ||
Working | Hydraulic System | Lifting Capacity at 610mm Behind Lift Point (KN) | 16 |
3-Point Suspension | Category:II | ||
P.T.O | Rotating | 720 or 540/1000 | |
Spline Size | 6-φ35Rectangular Spline | ||
OPTIONS | ROLL BAR,CANOPY,CAB,AIR BRAKE |
