Jinma, JM
Ttactor | Model | JM-950 | |
Drive Type | 2WD | ||
Overall Dimensions L*W*H(mm) | 4396*2038*2810 | ||
Wheel Track(mm) | Front | 1385-1685 | |
Rear | 1620 | ||
Wheel Base(mm) | 2208 | ||
Ground | 396 | ||
RatedTractionForce(N) | 18500 | ||
Construction Mass(kg) | 3620 | ||
Min.Turning Radius(m) | 3.8 | ||
TheoreticalSpeed(Withoutcreeper km/h) | Forward | 2.41 ,3.75 ,6.01 ,8.38,10.47 ,16.29 ,26.06,36.37 | |
Reverse | 3.24 ,5.04 | ||
TheoreticalSpeed(With creeper km/h) | Forward | 0.48,0.75,1.20,1.68 | |
Reverse | 0.65,1.01,1.61,2.25 | ||
Engine | Model | QC4115 | |
Type | 4 -cylinder 4-stroke cycle water cooled,direct-injection | ||
Rated Power(kw/hp) | 69.9(95) | ||
Rated Speed(rpm) | 2400 | ||
Bore*Stroke(mm) | 112*135 | ||
Total Displacement | 5.6 | ||
Drive | Clutch | Dual Stage | |
Gear Box | 4*(2+1)*2 Sleeve gear shift | ||
Main Drive | One pair of spiral bevel gear | ||
Differential | Bevel gear | ||
Differential Lock | Sliding pin,foot operated | ||
Final Transmission | Planetary reduction gear | ||
Traveling | Tyre | Front | 7.50-20 |
Rear | 16.9-34 | ||
Steering Gear | Hydraulic steering | ||
Brake | Oil immersed multiplate disc | ||
Working Device | Hydraulic System | Lifting Capacity at610mm Behind Lift Point(kg) | 15700 |
3-Point Suspension | Category:Ⅱ | ||
P.T.O.shaft | Rotating | 540/1000 or 720/1000 | |
Spkine Size | 21-φ35 involute spline | ||
OPTIONS | CAB |
