FOTMA
| Model | ZM1002 | ZM3004 | ZM5004 | ZM8006 | ZM10006 | ZM12006 |
| Matching Power | 10-25 hp | 20-50 hp | 30-60 hp | 50-80 hp | 70-100 hp | 80-140 hp |
| Machine Weight (kg) | 1010 | 1790 | 2040 | 2750 | 3000 | 3200 |
| 一： Trailer Section: | | | | | | |
| Trailer Model | TRIO | TR30 | TR50 | TR80 | TR100 | TR120 |
| N/W of Trailer (Kg) | 420 | 690 | 940 | 1450 | 1700 | 1900 |
| Rated Loading Capacity | IT | 3T | 5T | 8T | 10T | 12T |
| Loading Area | 0. 85m2 | lm2 | 1. 6m2 | 2.2m2 | 2. 5m2 | 2.8m2 |
| Total Length of Trailer | 3. 6m | 5. lm | 5. lm | 5. 9m | 6. 3m | 6. 3m |
| Trailer Loading Length | 2. 0m | 3. 1 m | 3. 1 m | 3.8 m | 4. 3 m | 4. 3 m |
| Total Width of Trailer | 1. 4 | 1.6 m | 1.8 m | 2.2 m | 2. 3 m | 2. 5 m |
| Assistant Hydraulic Steering | No | Standard | ||||
| Dia. of Traction Hole | 33 mm | 38 mm | ||||
| Tire Model | 6. 00-13 | 7. 00-16 | 8.25-16 | 400/60-15.5 | ||
| 二：Crane Section: | | |||||
| Modle | CR02 | CR04 | CR06 | |||
| Weight of Crane (Kg) | 590 | 1100 | 1300 | |||
| Max. Arm Reach | 3. 5m | 4.3 m | 6m | |||
| Lifting Capacity/Arm Reach(kg/m) | 400/2, | 900/2, 760/3, 500/4, 450/4. 3 | 990/2, 760/3, | |||
| 300/3, | | 500/4, | ||||
| 200/3. 5 | | 340/5, 240/6 | ||||
| Rotating Angle | 370° | 400° | 400° | |||
| Grab Sections: | ||||||
| Grab Model | TG019 | TG024 | TG029 | |||
| Weight of Grab (Kg) | 90 | 130 | 160 | |||
| Max. Grab Opening Width (mm) | 1140 | 1300 | 1430 | |||
| Grabbing Dia. of Logs (mm) | 80 〜420 | 70 〜485 | 75 〜530 | |||
| Power (Option): | PT0 / Gasoline Engine/ Diesel Engine | |||||
