7C
FOTMA
| Model | 7C-1 | 7C-2 | 7C-3 | 7C-4 | 7C-5 |
| Outside dimension(mm) | 2900*1200*400 | 3800*1550*1700 | 4300*1650*1800 | 4700*1900*1850 | 5100*2100*1900 |
| Loading capacity | 1 ton | 2 ton | 3 ton | 4 ton | 5 ton |
| Dead weight | 260kgs | 450kgs | 550kgs | 850kgs | 1000kgs |
| Tire/QTY | 600-14/2 | 700-16/2 | 750-16/2 | 825-16/2 | 750-16/4 |
| Brake forms | Hand or air brake | Hand or air brake | Hand or air brake | Hand or air brake | Hand or air brake |
| Match power | 12-18hp | 12-25hp | 18-40hp | 25-40hp | 25-50hp |
| Unload form | hydraulic | hydraulic | hydraulic | hydraulic | hydraulic |
| Model | 7C-1 | 7C-2 | 7C-3 | 7C-4 | 7C-5 |
| Outside dimension(mm) | 2900*1200*400 | 3800*1550*1700 | 4300*1650*1800 | 4700*1900*1850 | 5100*2100*1900 |
| Loading capacity | 1 ton | 2 ton | 3 ton | 4 ton | 5 ton |
| Dead weight | 260kgs | 450kgs | 550kgs | 850kgs | 1000kgs |
| Tire/QTY | 600-14/2 | 700-16/2 | 750-16/2 | 825-16/2 | 750-16/4 |
| Brake forms | Hand or air brake | Hand or air brake | Hand or air brake | Hand or air brake | Hand or air brake |
| Match power | 12-18hp | 12-25hp | 18-40hp | 25-40hp | 25-50hp |
| Unload form | hydraulic | hydraulic | hydraulic | hydraulic | hydraulic |
