FOTMA
Model | For Tractor | TX150 | TX165 | TX180 | TX210 | TX230 | TX260 |
For Front End Loader | TX150-TZ | TX165-TZ | TX180-TZ | TX210-TZ | TX230-TZ | TX260-TZ | |
For Front Linkage | TX150-XG | TX165-XG | TX180-XG | TX210-XG | TX230-XG | TX260-XG | |
Matching Tractor (hp) | 20 〜35 | 30 〜50 | 45 〜70 | 70 〜90 | 80 〜100 | 90 〜130 | |
Blade Width (Overall width) (mm) | 1500 | 1650 | 1800 | 2100 | 2300 | 2600 | |
Blade Height (mm) | 660 | 660 | 660 | 700 | 700 | 700 | |
L/R Swing Angle | Mechanical Type (standard ) | 0° /±16° /±30° | |||||
Hydraulic Type (option ) | -26。〜26° | ||||||
Cutting Width(mm) | 30° Angle | 1300 | 1430 | 1560 | 1820 | 2000 | 2250 |
26° Angle | 1350 | 1500 | 1620 | 1890 | 2070 | 2340 | |
Horizontal Tilting Angle | -5。〜5。 | ||||||
Hydraulic Controlling System | Share Tractor Hydraulic Valves(Standards) | ||||||
One-way Valve/Mechanical Swing, Double-way Valve/HydraulicSwing (Option) | |||||||
Weight (kg) | 180〜240 | 190 〜260 | 220〜300 | 300〜380 | 330〜410 | 350〜440 |
