| 18-25HP Wheeled Tractor Specifications | ||||
| Model | YTO-180 | YTO-200 | YTO-SE250 | YTO-SK244 |
| Diesel engine | ||||
| Model | TY295IT | TY295IT | TY2100IT3 | YD385T |
| Type | Double cylinder, vertical, water cooled, four stroke | |||
| Displacement (L) | 1.49 | 1.49 | 1.65 | 1.53 |
| Rated power/speed(Kw)/(r/min) | 13.2/2200 | 14.7/2200 | 18.4/2300 | 17.7/2350 |
| Max. torque (N.m)/speed (r/min) | 66.4/1760 | 71.5/1760 | 86/1760 | 83/1700 |
| Bore x stroke (mm) | 95×105 | 95×105 | 100×105 | 85×90 |
| Transmission | ||||
| Gear shift, forward/backward | 16/4 | 16/4 | 8/4 | 8/2 |
| Speed range (Km/h), forward/backward | 0.79-27.0/1.05-9.79 | 0.78-27.44/1.03-10.07 | 2.17-28.13/2.59-7.86 | 2.07-31.54/2.72-12.59 |
| PTO power (Kw) | 10.56 | 11.77 | 15.5 | 15.05 |
| PTO rotation speed(r/min) | 540 | 540 | 540 | 540/1000 |
| Clutch | Single disc | Single disc | Single disc | Single action (Double action optional) |
| Implement | ||||
| Three-point linkage category | Rear three-point linkage I | Rear three-point linkage I | Rear three-point linkage I | Rear three-point suspension I |
| Tilling depth control mode | Height adjustment | Height adjustment | Floating adjustment, position adjustment | Height adjustment, position adjustment |
| Lifting force(KN) | 2.98 | 3.2 | 4.2 | 4 |
| Dimensions, mass, drive | | | ||
| Drive type | 4×2 | 4×2 | 4×2 | 4×4 |
| Overall dimensions (LxWxH)(mm) | 2540×1205×1370 | 2800×1240×1400 | 3320×1280×1418 | 3453×1465×1835 |
| Wheelbase(mm) | 1440 | 1500 | 1650 | 1698 |
| Min. ground clearance(mm) | 271 | 305 | 325 | 260 |
| Min. operating mass(with safety stand)(Kg) | 1060 | 1060 | 1280 | 1450 |
| Tyre spec., front /rear | 4.0-14/7.5-20 | 4.0-14/9.5-20 | 4.0-16/9.5-24 | 6.0-16/9.5-24 |
| Wheel tread, front/rear | 1000/1000 | 1000/1020 | 1000-1300/1020 | 1190/1100-1300 |
| Steering | Mechanical | Hydraulic steering | ||
| Brake | Shoe, mechanical | - | ||
