YTO
Model | YTO-400 | YTO-404 | YTO-450 | YTO-454 |
Tractor | | | | |
Drive Type | 4×2 | 4×4 | 4×2 | 4×4 |
Overall Dimensions (L×W×H)(mm) | 3737×1650×2400 | 3727×1630×2400 | 3742×1645×2405 | 3742×1640×2435 |
Wheel Base (mm) | 1942 | 1965 | 1940 | 1900 |
Min. Ground Clearance (mm) | 410 | 270 | 380 | 350 |
Min. Operating Mass (kg)(ROPS) | 1820 | 1990 | 1820 | 2070 |
Tyre Size (F/R) | 6.00-16/12.4-28 | 7.5-16/11.2-28 | 6.00-16/12.4-28 | 8.3-20/12.4-28 |
Wheel Track (F/R) (mm) | 1350-1550/1300-1500 | 1250/1300-1600 | 1250-1450/1300-1500 | 1250/1300-1600 |
Gear Shift (F/R) | 8/4 | 8/4 | 8/4 | 8/4 |
Speed Range (km/h)(F/R) | 2.58-33.83/3.82-11.68 | 2.49-32.59/3.69-11.25 | 2.49-32.65/3.70-11.28 | 2.25-29.53/3.34-10.20 |
Lifting Force (610mm)(KN) | ≥6.62 | ≥6.62 | ≥7.45 | ≥7.45 |
Lifting Force (Link Joint)(KN) | 8.52 | 8.52 | 9.6 | 9.6 |
Diesel Engine | | | | |
Model | C490BT-8 | C490BT-8 | A495BT-5 | YT3B2-22 |
Type | 4-cylinder, in-line, vertical, water cooled, four stroke | 4-cylinder, in-line, vertical, water cooled, four stroke | 4-cylinder, in-line, vertical, water cooled, four stroke | 3-cylinder, in-line, vertical, water cooled, four stroke |
Displacement (L) | 2.67 | 2.67 | 2.76 | 3.3 |
Rated Power/Rotating Speed (kW/rpm) | 29.4/2400 | 29.4/2400 | 25.7/2200 | 33.1/2200 |
Model | YTO-400 | YTO-404 | YTO-450 | YTO-454 |
Tractor | | | | |
Drive Type | 4×2 | 4×4 | 4×2 | 4×4 |
Overall Dimensions (L×W×H)(mm) | 3737×1650×2400 | 3727×1630×2400 | 3742×1645×2405 | 3742×1640×2435 |
Wheel Base (mm) | 1942 | 1965 | 1940 | 1900 |
Min. Ground Clearance (mm) | 410 | 270 | 380 | 350 |
Min. Operating Mass (kg)(ROPS) | 1820 | 1990 | 1820 | 2070 |
Tyre Size (F/R) | 6.00-16/12.4-28 | 7.5-16/11.2-28 | 6.00-16/12.4-28 | 8.3-20/12.4-28 |
Wheel Track (F/R) (mm) | 1350-1550/1300-1500 | 1250/1300-1600 | 1250-1450/1300-1500 | 1250/1300-1600 |
Gear Shift (F/R) | 8/4 | 8/4 | 8/4 | 8/4 |
Speed Range (km/h)(F/R) | 2.58-33.83/3.82-11.68 | 2.49-32.59/3.69-11.25 | 2.49-32.65/3.70-11.28 | 2.25-29.53/3.34-10.20 |
Lifting Force (610mm)(KN) | ≥6.62 | ≥6.62 | ≥7.45 | ≥7.45 |
Lifting Force (Link Joint)(KN) | 8.52 | 8.52 | 9.6 | 9.6 |
Diesel Engine | | | | |
Model | C490BT-8 | C490BT-8 | A495BT-5 | YT3B2-22 |
Type | 4-cylinder, in-line, vertical, water cooled, four stroke | 4-cylinder, in-line, vertical, water cooled, four stroke | 4-cylinder, in-line, vertical, water cooled, four stroke | 3-cylinder, in-line, vertical, water cooled, four stroke |
Displacement (L) | 2.67 | 2.67 | 2.76 | 3.3 |
Rated Power/Rotating Speed (kW/rpm) | 29.4/2400 | 29.4/2400 | 25.7/2200 | 33.1/2200 |
